The application of ultrasonic cleaning machine in various fields

Ultrasonic cleaning has other physical and chemical or cleaning advantages, widely used in electronic industry, service industry, cemented carbide industry, laboratory, mechanical industry, medicine, chemical industry and many other fields, the following individual industries for a brief introduction.

1, the application of ultrasonic in micro powder industry

As we all know, to obtain particles of different sizes, is to put the crushing material in the ball mill after grinding, through different specifications of sieve layer by layer. Sieve after a long time of use, the sieve hole will be blocked (such as diamond sieve), with other methods of brushing will destroy the sieve, and the effect is not ideal, after the test of many manufacturers, with ultrasonic cleaning, not only does not damage the sieve, and the blocked particles above the sieve are completely recycled.

2. Ultrasonic cleaning of filter element

As we know, no matter what kind of material of the filter or filter, whatever the purpose to use after a period of time, will be caused by impurities permeability decrease and scrap, ordinary filter can also be low prices, but for chemical fiber industry, an import filter, nearly ten thousand yuan, the price of a pity, we work with other scientific research units of the ultrasonic wave filter cleaner, Using shaped ultrasonic cleaning machine, it can concentrate the energy of more than 1KW on the radiation surface of 20020mm2, ultrasonic intensity is large, can quickly remove the blockage, at the same time the equipment adopts anti-filtration device, as long as you provide the wave core, we can provide you with a complete set of cleaning device. (The equipment takes 10-15 minutes to wash a filter element). Suitable for PP cotton filter element, activated carbon filter element, hollow fiber filter element ceramic membrane filter element.

3. Application of ultrasonic cleaning technology in phosphating treatment

Product spraying pretreatment process is very important. The general traditional process uses acid to process the workpiece, which causes heavy environmental pollution and poor working environment. At the same time, the biggest disadvantage is that the residual acid after pickling and rust removal of complex parts is difficult to wash clean. After the workpiece spraying, the time is not long, along the crack corrosion phenomenon, damage the coating surface, seriously affect the product appearance and internal quality. Ultrasonic cleaning technology applied to the pretreatment of painting, not only can make the surface of the object and the dirt in the gap quickly peel off, and coating parts of the spray layer is firm and will not rust back.

4. Application in service industry

In daily production, glasses and jewelry can be cleaned with ultrasonic wave, with high speed and no damage. Large hotels and restaurants use it to clean tableware, which not only has good cleaning effect, but also has the effect of killing viruses.

5, the application of ultrasonic in pharmaceutical industry

Ultrasonic cleaning technology has been widely used by many pharmaceutical enterprises, especially for the cleaning of siilin bottles, oral liquid bottles, ampoule, large infusion bottles and butyl rubber plug, natural rubber plug cleaning, has been approved. For bottle cleaning, is to use ultrasonic cleaning technology instead of the original brush machine, it through the reverse water injection, ultrasonic cleaning, internal and external washing, air drying, turnover and other processes to achieve.

6, ultrasonic cleaning of metal

As we all know, after the metal bar is extruded into wire, the outer wire often has a layer of carbide film and oil, with acid cleaning or other cleaning methods, it is difficult to remove dirt (especially the whole plate wire), ultrasonic wire washing machine is designed according to the actual production needs of a continuous wire, efficient cleaning equipment, The rough cleaning part is composed of cleaning liquid storage tank, transducer, circulating pump, filter and supporting pipeline system. The metal wire is cleaned by ultrasonic rough cleaning and fine cleaning, and then through blow drying, so as to complete the whole cleaning process. The whole equipment integrated control, simple, convenient, good effect, widely used in tantalum wire, tungsten wire, molybdenum wire, niobium wire, copper wire (before insulating paint coating) and other metal wire.
